Volume pricing
- 1+ pcs$3.14
- 10+ pcs$2.96
- 100+ pcs$2.79
- 500+ pcs$2.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Peak Output Source Sink
- 1.25A 2A
- Uzunluk
- 8.65mm
- Driver Configuration
- Half-Bridge
- Max Supply Voltage
- 13.2V
- Genişlik
- 3.9mm
- Min. Çalışma Sıcaklığı
- 0°C
- Kılıf / Paket
- SOIC
- Terminal Pozisyonu
- DUAL
- Power Dissipation Max
- 1W
- Rise Time
- 26ns
- Besleme Gerilimi
- 12V
- Besleme Gerilimi
- 10.8V~13.2V
- Gate Type
- N-Channel MOSFET
- ECCN Kodu
- EAR99
- High Side Voltage Max Bootstrap
- 36V
- Number Of Drivers
- 4
- Maks. Oturma Yüksekliği
- 1.75mm
- Yayın Yılı
- 2001
- Pin Sayısı
- 14
- Power Supplies
- 12V
- Kurşunsuz
- Lead Free
- Rise Fall Time Typ
- 26ns 18ns
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- 0°C~125°C TJ
- Kurşunsuz Kodu
- yes
- Yüzey Montaj
- YES
- Qualification Status
- Not Qualified
- Max Output Current
- 3A
- Interface Ic Type
- HALF BRIDGE BASED MOSFET DRIVER
- Temperature Grade
- OTHER
- Terminal Formu
- GULL WING
- Montaj Tipi
- Surface Mount
- Terminal Kaplaması
- Matte Tin (Sn) - annealed
- Maks. Çalışma Sıcaklığı
- 85°C
- JESD-609 Kodu
- e3
- Terminal Adımı
- 1.27mm
- Temel Parça No
- ISL6614
- Fonksiyon Sayısı
- 2
- Montaj
- Surface Mount
- RoHS Durumu
- RoHS Compliant
