Specifications
- Besleme Gerilimi
- 12V
- Min Supply Voltage
- 7V
- Power Dissipation Max
- 2W
- Fonksiyon Sayısı
- 1
- Supply Voltage1nom
- 12V
- Max Output Current
- 3A
- Yayın Yılı
- 2001
- Montaj
- Surface Mount
- Terminal Kaplaması
- Matte Tin (Sn) - annealed
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Maks. Çalışma Sıcaklığı
- 85°C
- Interface Ic Type
- HALF BRIDGE BASED MOSFET DRIVER
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Fall Time Typ
- 18 ns
- Tepe Reflow Süresi (maks. sn)
- 40
- Çıkış Akımı
- 3A
- Operating Supply Current
- 10.5mA
- Kılıf / Paket
- SOP
- Output Peak Current Limitnom
- 3A
- Number Of Drivers
- 2
- Terminal Pozisyonu
- DUAL
- Terminal Formu
- GULL WING
- High Side Driver
- YES
- Max Supply Voltage
- 13.2V
- Kurşunsuz
- Lead Free
- Tepe Reflow Sıcaklığı (°C)
- 260
- JESD-609 Kodu
- e3
- Qualification Status
- Not Qualified
- Genişlik
- 3.9mm
- Temperature Grade
- OTHER
- Terminal Sayısı
- 8
- Pin Sayısı
- 8
- Pin Sayısı
- 8
- Rise Time
- 26ns
- Min. Çalışma Sıcaklığı
- 0°C
