Volume pricing
- 1+ pcs$1.18
- 10+ pcs$1.11
- 100+ pcs$1.05
- 500+ pcs$0.99
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Qualification Status
- Not Qualified
- Interface Ic Type
- LINE TRANSCEIVER
- Operating Temperature Max
- 70°C
- Nominal Supply Current
- 1μA
- Tepe Reflow Süresi (maks. sn)
- 30
- Tepe Reflow Sıcaklığı (°C)
- 240
- Parça Durumu
- Discontinued
- RoHS Durumu
- Non-RoHS Compliant
- Out Swingmin
- 10 V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Supply Voltagemax Vsup
- 5.5V
- Pin Sayısı
- 20
- Power Supplies
- 3.3/5V
- Kurşunsuz
- Contains Lead
- Terminal Sayısı
- 20
- Interface Standards
- EIA-232; TIA-232; V.24; V.28
- Maks. Oturma Yüksekliği
- 1.2mm
- Terminal Adımı
- 0.65mm
- Yayın Yılı
- 2001
- Fonksiyon Sayısı
- 2
- Input Characteristics
- SCHMITT TRIGGER
- Montaj
- Surface Mount
- JESD-609 Kodu
- e0
- Supply Voltagemin Vsup
- 3V
- ECCN Kodu
- EAR99
- Jesd30 Code
- R-PDSO-G20
- Terminal Pozisyonu
- DUAL
- Terminal Kaplaması
- Tin/Lead (Sn/Pb)
- Receiver Number Of Bits
- 2
- Driver Number Of Bits
- 2
- HTS Kodu
- 8542.39.00.01
- Output Low Currentmax
- 0.0016A
- Receive Delaymax
- 300 ns
- REACH Uyumluluk Kodu
- not_compliant
- Besleme Gerilimi
- 3.3V
- Data Rate
- 250 kbps
- Differential Output
- NO
- Temperature Grade
- COMMERCIAL
- Terminal Formu
- GULL WING
- Uzunluk
- 6.5mm
