Specifications
- Temel Parça No
- EL7154
- Montaj Tipi
- Surface Mount
- Number Of Drivers
- 1
- Power Dissipation Max
- 570mW
- Driver Configuration
- High-Side or Low-Side
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- ECCN Kodu
- EAR99
- Terminal Kaplaması
- Matte Tin (Sn) - annealed
- Max Supply Current
- 2.5mA
- Output Current Flow Direction
- SOURCE SINK
- JESD-609 Kodu
- e3
- Maks. Çalışma Sıcaklığı
- 85°C
- Çıkış Akımı
- 4A
- Max Supply Voltage
- 16V
- Besleme Gerilimi
- 12V
- Qualification Status
- Not Qualified
- Min. Çalışma Sıcaklığı
- -40°C
- Pin Sayısı
- 8
- Output Peak Current Limitnom
- 4A
- Ambalaj
- Tape & Reel (TR)
- Logic Voltagevil Vih
- 0.6V 2.4V
- Rise Time
- 25ns
- Giriş Tipi
- Non-Inverting
- Besleme Gerilimi
- 4.5V~16V
- Output Current Per Channel
- 200mA
- Temperature Grade
- INDUSTRIAL
- Terminal Sayısı
- 8
- Kurşunsuz
- Lead Free
- Montaj
- Surface Mount
- Fall Time Typ
- 25 ns
- Pin Sayısı
- 8
- RoHS Durumu
- RoHS Compliant
- Channel Type
- Synchronous
- Rise Fall Time Typ
- 4ns 4ns
- Yayın Yılı
- 2002
- Interface Ic Type
- BUFFER OR INVERTER BASED PERIPHERAL DRIVER
- Min Supply Voltage
- 4.5V
- Supply Voltage1nom
- 12V
- Current Peak Output Source Sink
- 4A 4A
