EPM9560ARC240-10

Specifications

Qualification Status

Not Qualified

Operating Temperaturemax

70 °C

Seri

MAX® 9000A

Maks. Oturma Yüksekliği

4.1mm

Temperature Grade

COMMERCIAL

Jesd30 Code

S-PQFP-G240

Terminal Sayısı

240

Kılıf / Paket

240-BFQFP Exposed Pad

Number Of Ios

191

Terminal Pozisyonu

QUAD

Üretici Parça No

EPM9560ARC240-10

Power Supplies

3.3/55V

REACH Uyumluluk Kodu

compliant

Output Function

MACROCELL

Tepe Reflow Sıcaklığı (°C)

220

Package Code

FQFP

Parça Durumu

Obsolete

Supply Voltagenom

5 V

Part Package Code

QFP

Tepe Reflow Süresi (maks. sn)

30

Supply Voltagemin

4.75 V

Clock Frequency

144.9MHz

Supply Voltagemax

5.25 V

Temel Parça No

EPM9560

Tedarikçi Cihaz Paketi

240-RQFP (32x32)

Genişlik

32mm

Çalışma Sıcaklığı

0°C~70°C TA

Nem Hassasiyeti (MSL)

3 (168 Hours)

Uzunluk

32mm

Number Of Io Lines

191

Package Body Material

PLASTIC/EPOXY

Organization

0 DEDICATED INPUTS, 191 I/O

Package Style

FLATPACK, FINE PITCH

Package Equivalence Code

HQFP240,1.37SQ,20

Insystem Programmable

YES

Propagation Delay

11.4 ns

HTS Kodu

8542.39.00.01

Rohs Code

No

Seated Heightmax

4.1 mm

Additional Feature

560 MACROCELLS; 35 LABS; 772 FLIP FLOPS; CONFIGURABLE I/O OPERATION WITH 3.3V OR 5V
