TLE4998S8XUMA1

Specifications

Parça Durumu

Active

RoHS Durumu

ROHS3 Compliant

Nem Hassasiyeti (MSL)

3 (168 Hours)

Fabrika Tedarik Süresi

39 Weeks

Body Breadth

3.9 mm

Montaj Tipi

Surface Mount

Magnetic Field Rangemax

200 mT

Termination Type

SOLDER

Output Current

5mA

Ambalaj

Tape & Reel (TR)

Çalışma Sıcaklığı

-40°C~125°C TA

Output Range

0-5mA

Seri

Automotive, AEC-Q100

Current Supply Max

8mA

JESD-609 Kodu

e3

Terminal Kaplaması

Tin (Sn)

Yüzey Montaj

YES

Özellikler

Programmable

Body Height

1.2mm

Yayın Yılı

2016

Housing

PLASTIC

Kılıf / Paket

8-SOIC (0.154, 3.90mm Width)

Sensing Range

±50mT ~ ±200mT

Çıkış Tipi

Open Drain

Magnetic Field Rangemin

-50 mT

Additional Feature

AEC-Q100; IT ALSO OPERATES AT EXTENDED RANGE 4.1 TO 16V SUPPLY VOLTAGE; IT HAS SENSITIVITY OF 245 LSB12/MT; SHORT-CIRCUIT PROTECTION

Body Length Or Diameter

5mm

Resolution

16 b

Besleme Gerilimi

4.5V~5.5V

Axis

Single
