SIDC23D60E6X1SA4

Specifications

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Ambalaj

Bulk

Terminal Sayısı

1

Kurşunsuz

Contains Lead

Configuration

SINGLE

Nem Hassasiyeti (MSL)

1 (Unlimited)

Speed

Standard Recovery >500ns, > 200mA (Io)

Kurşunsuz Kodu

no

Qualification Status

Not Qualified

Terminal Formu

NO LEAD

Tepe Reflow Sıcaklığı (°C)

NOT SPECIFIED

Yayın Yılı

2005

Montaj

Surface Mount

Montaj Tipi

Surface Mount

Number Of Elements

1

Diode Type

Standard

Operating Temperature Max

150°C

ECCN Kodu

EAR99

Max Dual Supply Voltage

600V

Kılıf / Paket

Die

Voltage Forward Vf Max If

1.25V @ 50A

Terminal Pozisyonu

UPPER

Pin Sayısı

1

Drain To Source Voltage Vdss

600V

Applications

FAST SOFT RECOVERY

Operating Temperature Junction

-55°C~150°C

HTS Kodu

8541.10.00.40

Max Reverse Voltage Dc

600V

Diode Element Material

SILICON

Current Reverse Leakage Vr

27μA @ 600V

Number Of Phases

1

Current Average Rectified Io

50A DC

Jesd30 Code

R-XUUC-N1

Halogen Free

Halogen Free

RoHS Durumu

Non-RoHS Compliant

Output Current

50A

Average Rectified Current

50A

Parça Durumu

Last Time Buy
