Volume pricing
- 1+ pcs$10.36
- 10+ pcs$9.77
- 100+ pcs$9.22
- 500+ pcs$8.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Function
- Driver - Fully Integrated, Control and Power Stage
- Reach Svhc
- No SVHC
- Besleme Gerilimi
- 13.5V~16.5V
- Isolation Voltage
- 1.5kV
- Turn Off Delay Time
- 1.5 μs
- Voltage Load
- 200V Max
- Terminal Sayısı
- 36
- Uzunluk
- 12mm
- Besleme Gerilimi
- 15V
- Switchingfrequency
- 20kHz
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Genişlik
- 12mm
- Collector Emitter Voltage Vceo
- 250V
- Motor Type Ac Dc
- AC, Synchronous
- Ambalaj
- Tray
- Terminal Pozisyonu
- QUAD
- Interface
- Parallel
- Radyasyon Dayanımı
- No
- Turn On Delay Time
- 1.5 μs
- Nominal Supply Current
- 125μA
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Number Of Outputs
- 3
- Yayın Yılı
- 2013
- Montaj
- PCB, Surface Mount
- Applications
- Appliance
- Analog Ic Other Type
- AC MOTOR CONTROLLER
- Parça Durumu
- Active
- Power Supplies
- 15V
- Max Supply Current
- 10mA
- Max Output Current
- 2A
- Output Configuration
- Half Bridge (3)
- Fabrika Tedarik Süresi
- 18 Weeks
- Yükseklik
- 950μm
- RoHS Durumu
- ROHS3 Compliant
- Pin Sayısı
- 36
- Logic Function
- AND
- Max Collector Current
- 2A
- Kurşunsuz
- Lead Free
- Max Power Dissipation
- 16W
- Number Of Drivers
- 6
