Specifications
- Özellikler
- Bootstrap Circuit
- Kılıf / Paket
- 23-DIP Module
- Montaj Tipi
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Output Configuration
- Half Bridge (3)
- Fonksiyon Sayısı
- 1
- Load Type
- Inductive
- Fabrika Tedarik Süresi
- 21 Weeks
- HTS Kodu
- 8542.39.00.01
- Maks. Oturma Yüksekliği
- 3.15mm
- Applications
- AC Motors
- Jesd30 Code
- R-XDMA-T23
- Analog Ic Other Type
- AC MOTOR CONTROLLER
- Parça Durumu
- Obsolete
- Seri
- µIPM™-DIP
- Yayın Yılı
- 2014
- Supply Voltagemin Vsup
- 13.5V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Fault Protection
- UVLO
- Rds On Typ
- 340m Ω
- Terminal Pozisyonu
- DUAL
- Interface
- Logic
- Ambalaj
- Tube
- Supply Voltagemax Vsup
- 16.5V
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Genişlik
- 14mm
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Yüzey Montaj
- NO
- Terminal Sayısı
- 23
- Uzunluk
- 29mm
- Besleme Gerilimi
- 15V
- Voltage Load
- 200V Max
- Besleme Gerilimi
- 13.5V~16.5V
