Volume pricing
- 1+ pcs$5.67
- 10+ pcs$5.35
- 100+ pcs$5.05
- 500+ pcs$4.76
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Giriş Tipi
- Inverting
- Gate Type
- IGBT, N-Channel MOSFET
- Max Power Dissipation
- 2W
- Input Characteristics
- STANDARD
- Terminal Kaplaması
- Matte Tin (Sn)
- High Side Driver
- YES
- Number Of Drivers
- 6
- Output Current
- 200mA
- High Side Voltage Max Bootstrap
- 600V
- Uzunluk
- 6.985mm
- Turn Off Delay Time
- 530 ns
- Max Output Current
- 350mA
- Output Peak Current Limitnom
- 0.35A
- Yayın Yılı
- 1996
- Propagation Delay
- 750 ns
- Turn Off Time
- 0.75 μs
- RoHS Durumu
- ROHS3 Compliant
- Rise Fall Time Typ
- 125ns 50ns
- Direnç
- 100Ohm
- Fall Time Typ
- 75 ns
- HTS Kodu
- 8542.39.00.01
- Temel Parça No
- IRS2336DMPBF
- Channel Type
- 3-Phase
- Interface Ic Type
- BUFFER OR INVERTER BASED MOSFET DRIVER
- Driver Configuration
- Half-Bridge
- Genişlik
- 7.0104mm
- Current Peak Output Source Sink
- 200mA 350mA
- Fabrika Tedarik Süresi
- 18 Weeks
- Turn On Time
- 0.75 μs
- Pin Sayısı
- 34
- Yükseklik
- 939.8μm
- Terminal Pozisyonu
- QUAD
- JESD-609 Kodu
- e3
- ECCN Kodu
- EAR99
- Turn On Delay Time
- 530 ns
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Fonksiyon Sayısı
- 1
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Terminal Formu
- NO LEAD
- Terminal Sayısı
- 34
