Volume pricing
- 1+ pcs$22.40
- 10+ pcs$21.14
- 100+ pcs$19.94
- 500+ pcs$18.81
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Input Bias Current
- 200μA
- Turn On Delay Time
- 600 ns
- Besleme Gerilimi
- 15V
- Max Supply Voltage
- 15V
- Power Supplies
- 15400V
- Configuration
- 3 Phase
- Fonksiyon Sayısı
- 1
- Operating Supply Current
- 165μA
- Pin Sayısı
- 23
- Maks. Çalışma Sıcaklığı
- 125°C
- Yükseklik
- 25.8mm
- Montaj Tipi
- Through Hole
- Seri
- iMOTION™
- Genişlik
- 5.5mm
- Kılıf / Paket
- 23-PowerSIP Module, 19 Leads, Formed Leads
- Power Dissipation
- 38W
- Reach Svhc
- No SVHC
- Temperature Grade
- AUTOMOTIVE
- Terminal Pozisyonu
- ZIG-ZAG
- Voltage Isolation
- 2000Vrms
- Turn Off Delay Time
- 700 ns
- Max Output Current
- 20A
- Max Collector Current
- 20A
- Frekans
- 20kHz
- Radyasyon Dayanımı
- No
- Number Of Outputs
- 3
- Yayın Yılı
- 2004
- Fabrika Tedarik Süresi
- 13 Weeks
- Terminal Adımı
- 1.98mm
- Tip
- IGBT
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz
- Lead Free
- Parça Durumu
- Obsolete
- Nominal Supply Current
- 165μA
- Output Current
- 6A
- Montaj
- PCB, Through Hole
- Min. Çalışma Sıcaklığı
- -40°C
- Collector Emitter Voltage Vceo
- 600V
- Terminal Sayısı
- 23
- Max Output Voltage
- 600V
