Specifications
- Output Voltage
- 450V
- Min Supply Voltage
- 12V
- Operating Supply Voltage
- 15V
- Uzunluk
- 61.976mm
- Collectoremitter Breakdown Voltage
- 600V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- PCB, Through Hole
- Output Current
- 16A
- Nominal Supply Current
- 120μA
- Parça Durumu
- Obsolete
- Jesd30 Code
- R-XZFM-T19
- Terminal Sayısı
- 19
- Collector Emitter Voltage Vceo
- 600V
- Min. Çalışma Sıcaklığı
- -40°C
- Switchingfrequency
- 20kHz
- Yayın Yılı
- 2005
- Terminal Adımı
- 1.98mm
- Fabrika Tedarik Süresi
- 13 Weeks
- Tip
- IGBT
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Max Power Dissipation
- 31W
- Radyasyon Dayanımı
- No
- Number Of Outputs
- 3
- Frekans
- 20kHz
- Turn Off Delay Time
- 660 ns
- Voltage Isolation
- 2000Vrms
- Max Collector Current
- 16A
- Power Dissipation
- 35W
- Genişlik
- 5.5mm
- Kılıf / Paket
- 23-PowerSIP Module, 19 Leads, Formed Leads
- Collectoremitter Saturation Voltage
- 600V
- Terminal Pozisyonu
- ZIG-ZAG
- Reach Svhc
- No SVHC
- Pin Sayısı
- 23
- Maks. Çalışma Sıcaklığı
- 125°C
- Configuration
- 3 Phase
- Operating Supply Current
- 3.35mA
- Fonksiyon Sayısı
- 1
