Volume pricing
- 1+ pcs$15.67
- 10+ pcs$14.78
- 100+ pcs$13.94
- 500+ pcs$13.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Power Dissipation
- 27W
- Radyasyon Dayanımı
- No
- Number Of Outputs
- 3
- Frekans
- 20kHz
- Yayın Yılı
- 2005
- Terminal Adımı
- 1.98mm
- Fabrika Tedarik Süresi
- 99 Weeks
- Tip
- IGBT
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz
- Lead Free
- Montaj
- Through Hole
- Output Current
- 10A
- Parça Durumu
- Obsolete
- Nominal Supply Current
- 165μA
- Jesd30 Code
- R-XZFM-T25
- Terminal Sayısı
- 25
- Collector Emitter Voltage Vceo
- 600V
- Min. Çalışma Sıcaklığı
- -40°C
- Switchingfrequency
- 20kHz
- Output Voltage
- 450V
- Min Supply Voltage
- 12V
- Uzunluk
- 61.976mm
- Rms Current Irms
- 10A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Collectoremitter Breakdown Voltage
- 600V
- Quiescent Current
- 165μA
- Input Bias Current
- 200μA
- Power Supplies
- 15V
- Besleme Gerilimi
- 15V
- Max Supply Voltage
- 20V
- Pin Sayısı
- 23
- Maks. Çalışma Sıcaklığı
- 125°C
- Configuration
- 3 Phase
- Fonksiyon Sayısı
- 1
- Montaj Tipi
- Through Hole
- Seri
- iMOTION™
- Yükseklik
- 5.0038mm
- Terminal Kaplaması
- TIN LEAD
- Power Dissipation
- 2.2W
- Genişlik
- 5mm
