Specifications
- Configuration
- SINGLE
- Montaj Tipi
- Surface Mount
- Parça Durumu
- Active
- Igbt Type
- Trench Field Stop
- Seri
- TrenchStop™
- Kılıf / Paket
- Die
- Yayın Yılı
- 2015
- Max Dual Supply Voltage
- 1.2kV
- Yüzey Montaj
- YES
- Transistor Element Material
- SILICON
- Vceon Max Vge Ic
- 2.07V @ 15V, 25A
- Drain To Source Voltage Vdss
- 1.2kV
- Current Collector Pulsed Icm
- 75A
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 12 Weeks
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Polaritychannel Type
- N-CHANNEL
- RoHS Durumu
- ROHS3 Compliant
- Halogen Free
- Halogen Free
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Terminal Sayısı
- 2
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Elements
- 1
- Giriş Tipi
- Standard
- Transistor Application
- POWER CONTROL
- Terminal Formu
- NO LEAD
- Çalışma Sıcaklığı
- -40°C~175°C TJ
- Terminal Pozisyonu
- UPPER
- Jesd30 Code
- R-XUUC-N2
- Voltage Collector Emitter Breakdown Max
- 1200V
- Collector Emitter Voltage Vceo
- 1.2kV
