Volume pricing
- 1+ pcs$75.83
- 10+ pcs$71.53
- 100+ pcs$67.49
- 500+ pcs$63.67
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Turn Off Timenom Toff
- 570 ns
- Yayın Yılı
- 2002
- Additional Feature
- UL RECOGNIZED
- Power Max
- 385W
- Configuration
- Full Bridge
- Montaj
- Base
- Terminal Formu
- UNSPECIFIED
- Transistor Application
- POWER CONTROL
- Turn On Time
- 185 ns
- Terminal Pozisyonu
- UPPER
- Montaj Tipi
- Chassis Mount
- Kılıf / Paket
- Module
- RoHS Durumu
- ROHS3 Compliant
- Jesd30 Code
- R-XUFM-X34
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Case Connection
- ISOLATED
- Parça Durumu
- Active
- Vceon Max Vge Ic
- 2.15V @ 15V, 75A
- ECCN Kodu
- EAR99
- Currentcollector Ic Max
- 150A
- Terminal Sayısı
- 34
- Voltage Collector Emitter Breakdown Max
- 1200V
- Fabrika Tedarik Süresi
- 36 Weeks
- Number Of Elements
- 6
- Transistor Element Material
- SILICON
- Ntc Thermistor
- Yes
- Input
- Standard
- Halogen Free
- Not Halogen Free
- Kurşunsuz
- Contains Lead
- Current Collector Cutoff Max
- 1mA
- Igbt Type
- Trench Field Stop
- Çalışma Sıcaklığı
- -40°C~150°C
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Polaritychannel Type
- N-CHANNEL
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Input Capacitance Cies Vce
- 4.3nF @ 25V
