IDM10G120C5XTMA1

Specifications

Ambalaj

Tape & Reel (TR)

Operating Temperature Junction

-55°C~150°C

Seri

CoolSiC™+

Diode Type

Silicon Carbide Schottky

Average Rectified Current

38A

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Tepe Reflow Sıcaklığı (°C)

NOT SPECIFIED

Power Dissipation Max

223W

Yayın Yılı

2015

Additional Feature

PD-CASE

Current Average Rectified Io

38A DC

Jesd30 Code

R-PSSO-G2

Terminal Sayısı

2

Terminal Pozisyonu

SINGLE

Applications

EFFICIENCY

Voltage Forward Vf Max If

1.8V @ 10A

Number Of Elements

1

RoHS Durumu

ROHS3 Compliant

Parça Durumu

Active

Speed

No Recovery Time > 500mA (Io)

Fabrika Tedarik Süresi

16 Weeks

Kılıf / Paket

TO-252-3, DPak (2 Leads + Tab), SC-63

Nem Hassasiyeti (MSL)

1 (Unlimited)

Kurşunsuz

Lead Free

Current Reverse Leakage Vr

62μA @ 12V

Montaj Tipi

Surface Mount

JESD-609 Kodu

e3

Halogen Free

Halogen Free

Terminal Formu

GULL WING

Max Reverse Voltage Dc

1.2kV

Capacitance Vr F

29pF @ 800V 1MHz

Kurşunsuz Kodu

yes

Operating Temperature Max

175°C

Terminal Kaplaması

Tin (Sn)

Forward Current

38A

ECCN Kodu

EAR99

Case Connection

CATHODE

Montaj

Surface Mount

Reverse Recovery Time

0ns

Configuration

SINGLE
