Volume pricing
- 1+ pcs$138.67
- 10+ pcs$130.82
- 100+ pcs$123.41
- 500+ pcs$116.43
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Turn On Time
- 370 ns
- Power Max
- 4300W
- Voltage Collector Emitter Breakdown Max
- 1200V
- Collector Emitter Voltage Vceo
- 1.2kV
- Ntc Thermistor
- No
- Kılıf / Paket
- Module
- Vceon Max Vge Ic
- 2.1V @ 15V, 900A
- Turn Off Timenom Toff
- 810 ns
- Pin Sayısı
- 5
- Current Collector Cutoff Max
- 5mA
- Collectoremitter Saturation Voltage
- 2.1V
- Terminal Pozisyonu
- UPPER
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Currentcollector Ic Max
- 900A
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- yes
- Input
- Standard
- Yayın Yılı
- 2016
- Igbt Type
- Trench Field Stop
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Jesd30 Code
- R-XUFM-X5
- Seri
- C
- Number Of Elements
- 1
- Input Capacitance Cies Vce
- 56nF @ 25V
- ECCN Kodu
- EAR99
- Terminal Sayısı
- 5
- Montaj
- Screw
- Pin Sayısı
- 4
- Configuration
- Single
- Case Connection
- ISOLATED
- Fabrika Tedarik Süresi
- 14 Weeks
- Power Dissipation
- 4.3kW
