Specifications
- Polaritychannel Type
- N-CHANNEL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -40°C~125°C
- Currentcollector Ic Max
- 1300A
- Montaj Tipi
- Chassis Mount
- Terminal Formu
- UNSPECIFIED
- Kurşunsuz Kodu
- no
- Power Dissipationmax Abs
- 9600W
- Input
- Standard
- Pin Sayısı
- 7
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 5mA
- Terminal Pozisyonu
- UPPER
- Ntc Thermistor
- No
- Kılıf / Paket
- Module
- Gateemitter Voltagemax
- 20V
- Vceon Max Vge Ic
- 4.25V @ 15V, 800A
- Turn Off Timenom Toff
- 1900 ns
- Turn On Time
- 480 ns
- Power Max
- 9600W
- Voltage Collector Emitter Breakdown Max
- 3300V
- Case Connection
- ISOLATED
- ECCN Kodu
- EAR99
- Vcesatmax
- 4.25 V
- Terminal Sayısı
- 7
- Configuration
- Half Bridge
- Jesd30 Code
- R-XUFM-X7
- Number Of Elements
- 2
- Input Capacitance Cies Vce
- 100nF @ 25V
- Yayın Yılı
- 2002
- RoHS Durumu
- Non-RoHS Compliant
- Yüzey Montaj
- NO
- Parça Durumu
- Last Time Buy
