Specifications
- Max Collector Current
- 800A
- Genişlik
- 61.4mm
- Input Capacitance Cies Vce
- 56nF @ 25V
- Number Of Elements
- 1
- RoHS Durumu
- ROHS3 Compliant
- Yayın Yılı
- 2002
- Igbt Type
- Trench Field Stop
- Parça Durumu
- Active
- Case Connection
- ISOLATED
- Transistor Application
- POWER CONTROL
- Fabrika Tedarik Süresi
- 14 Weeks
- Uzunluk
- 106.4mm
- Terminal Sayısı
- 4
- ECCN Kodu
- EAR99
- Configuration
- Single
- Montaj
- Screw
- Pin Sayısı
- 4
- Kılıf / Paket
- Module
- Ntc Thermistor
- No
- Turn Off Timenom Toff
- 1000 ns
- Vceon Max Vge Ic
- 2.15V @ 15V, 800A
- Voltage Collector Emitter Breakdown Max
- 1200V
- Power Max
- 3550W
- Turn On Time
- 440 ns
- Collector Emitter Voltage Vceo
- 1.2kV
- Kurşunsuz Kodu
- yes
- Terminal Formu
- UNSPECIFIED
- Montaj Tipi
- Chassis Mount
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Yükseklik
- 36.5mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Polaritychannel Type
- N-CHANNEL
- Input
- Standard
- Current Collector Cutoff Max
- 5mA
- Transistor Element Material
- SILICON
- Pin Sayısı
- 5
- Terminal Pozisyonu
- UPPER
