Volume pricing
- 1+ pcs$134.57
- 10+ pcs$126.95
- 100+ pcs$119.76
- 500+ pcs$112.98
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Input
- Standard
- Montaj Tipi
- Chassis Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -40°C~125°C
- Polaritychannel Type
- N-CHANNEL
- Kurşunsuz Kodu
- yes
- Terminal Formu
- UNSPECIFIED
- Terminal Pozisyonu
- UPPER
- Collectoremitter Saturation Voltage
- 3.2V
- Current Collector Cutoff Max
- 5mA
- Pin Sayısı
- 5
- Transistor Element Material
- SILICON
- Turn Off Timenom Toff
- 590 ns
- Vceon Max Vge Ic
- 3.75V @ 15V, 600A
- Ntc Thermistor
- No
- Kılıf / Paket
- Module
- Collector Emitter Voltage Vceo
- 1.2kV
- Voltage Collector Emitter Breakdown Max
- 1200V
- Power Max
- 3900W
- Turn On Time
- 180 ns
- Fabrika Tedarik Süresi
- 14 Weeks
- Power Dissipation
- 3.9kW
- Case Connection
- ISOLATED
- Configuration
- Single
- Montaj
- Screw
- Pin Sayısı
- 4
- ECCN Kodu
- EAR99
- Terminal Sayısı
- 5
- Number Of Elements
- 1
- Input Capacitance Cies Vce
- 39nF @ 25V
- Max Collector Current
- 700A
- Jesd30 Code
- R-XUFM-X5
- Parça Durumu
- Active
- Yayın Yılı
- 2002
- RoHS Durumu
- ROHS3 Compliant
