Volume pricing
- 1+ pcs$105.09
- 10+ pcs$99.14
- 100+ pcs$93.53
- 500+ pcs$88.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Sayısı
- 4
- ECCN Kodu
- EAR99
- Configuration
- Single
- Transistor Application
- POWER CONTROL
- RoHS Durumu
- ROHS3 Compliant
- Igbt Type
- Trench Field Stop
- Yayın Yılı
- 2002
- Yüzey Montaj
- NO
- Parça Durumu
- Active
- Jesd30 Code
- R-XUFM-X4
- Input Capacitance Cies Vce
- 42nF @ 25V
- Number Of Elements
- 1
- Pin Sayısı
- 5
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 5mA
- Terminal Pozisyonu
- UPPER
- Terminal Formu
- UNSPECIFIED
- Kurşunsuz Kodu
- yes
- Polaritychannel Type
- N-CHANNEL
- Montaj Tipi
- Chassis Mount
- Currentcollector Ic Max
- 600A
- Çalışma Sıcaklığı
- -40°C~150°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input
- Standard
- Turn On Time
- 370 ns
- Voltage Collector Emitter Breakdown Max
- 1200V
- Kılıf / Paket
- Module
- Ntc Thermistor
- No
- Turn Off Timenom Toff
- 840 ns
- Vceon Max Vge Ic
- 2.05V @ 15V, 600A
