Volume pricing
- 1+ pcs$147.45
- 10+ pcs$139.11
- 100+ pcs$131.23
- 500+ pcs$123.80
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Polaritychannel Type
- N-CHANNEL
- Collectoremitter Breakdown Voltage
- 1.2kV
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yükseklik
- 36.5mm
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Montaj Tipi
- Chassis Mount
- Terminal Formu
- UNSPECIFIED
- Kurşunsuz Kodu
- yes
- Input
- Standard
- Pin Sayısı
- 5
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 5mA
- Max Power Dissipation
- 2.8kW
- Terminal Pozisyonu
- UPPER
- Collectoremitter Saturation Voltage
- 1.7V
- Ntc Thermistor
- Yes
- Kılıf / Paket
- Module
- Turn Off Timenom Toff
- 830 ns
- Vceon Max Vge Ic
- 2.15V @ 15V, 600A
- Power Max
- 2800W
- Turn On Time
- 400 ns
- Voltage Collector Emitter Breakdown Max
- 1200V
- Collector Emitter Voltage Vceo
- 1.2kV
- Reach Svhc
- No SVHC
- Rise Time
- 90ns
- Case Connection
- ISOLATED
- Uzunluk
- 106.4mm
- Transistor Application
- POWER CONTROL
- Fabrika Tedarik Süresi
- 14 Weeks
- Qualification Status
- Not Qualified
- Power Dissipation
- 2.8kW
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- ECCN Kodu
- EAR99
- Terminal Sayısı
- 3
- Pin Sayısı
- 4
- Montaj
- Screw
- Configuration
- Single
- Max Collector Current
- 900A
- Genişlik
- 61.4mm
- Jesd30 Code
- R-XUFM-X3
