Volume pricing
- 1+ pcs$103.38
- 10+ pcs$97.53
- 100+ pcs$92.01
- 500+ pcs$86.80
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pin Sayısı
- 4
- Montaj
- Panel, Screw
- Configuration
- Single
- Terminal Sayısı
- 5
- ECCN Kodu
- EAR99
- Power Dissipation
- 2.25kW
- Fabrika Tedarik Süresi
- 14 Weeks
- Uzunluk
- 106.4mm
- Case Connection
- ISOLATED
- Parça Durumu
- Active
- RoHS Durumu
- ROHS3 Compliant
- Yayın Yılı
- 2012
- Input Capacitance Cies Vce
- 28nF @ 25V
- Number Of Elements
- 1
- Jesd30 Code
- R-XUFM-X5
- Genişlik
- 61.4mm
- Max Collector Current
- 650A
- Terminal Pozisyonu
- UPPER
- Collectoremitter Saturation Voltage
- 1.7V
- Max Power Dissipation
- 2.25kW
- Pin Sayısı
- 5
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 5mA
- Input
- Standard
- Terminal Formu
- UNSPECIFIED
- Kurşunsuz Kodu
- yes
- Polaritychannel Type
- N-CHANNEL
- Montaj Tipi
- Chassis Mount
- Çalışma Sıcaklığı
- -40°C~125°C
- Yükseklik
- 36.5mm
- Collectoremitter Breakdown Voltage
- 1.2kV
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Collector Emitter Voltage Vceo
- 1.2kV
- Turn On Time
- 400 ns
- Power Max
- 2250W
- Voltage Collector Emitter Breakdown Max
- 1200V
- Vceon Max Vge Ic
- 2.15V @ 15V, 400A
- Turn Off Timenom Toff
- 830 ns
- Kılıf / Paket
- Module
- Ntc Thermistor
- No
