Volume pricing
- 1+ pcs$103.44
- 10+ pcs$97.58
- 100+ pcs$92.06
- 500+ pcs$86.85
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 5mA
- Max Power Dissipation
- 2.25kW
- Terminal Pozisyonu
- UPPER
- Kurşunsuz
- Lead Free
- Polaritychannel Type
- N-CHANNEL
- Montaj Tipi
- Chassis Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yükseklik
- 36.5mm
- Çalışma Sıcaklığı
- -40°C~125°C
- Terminal Formu
- UNSPECIFIED
- Kurşunsuz Kodu
- yes
- Input
- Standard
- Turn On Time
- 400 ns
- Power Max
- 2250W
- Voltage Collector Emitter Breakdown Max
- 1200V
- Collector Emitter Voltage Vceo
- 1.2kV
- Ntc Thermistor
- No
- Kılıf / Paket
- Module
- Vceon Max Vge Ic
- 2.15V @ 15V, 400A
- Turn Off Timenom Toff
- 830 ns
- ECCN Kodu
- EAR99
- Terminal Sayısı
- 5
- Montaj
- Panel, Screw
- Pin Sayısı
- 5
- Configuration
- Single
- Halogen Free
- Not Halogen Free
- Case Connection
- ISOLATED
- Uzunluk
- 106.4mm
- Fabrika Tedarik Süresi
- 14 Weeks
- Yayın Yılı
- 2002
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Genişlik
- 61.4mm
- Max Collector Current
- 650A
- Number Of Elements
- 1
- Input Capacitance Cies Vce
- 28nF @ 25V
