Volume pricing
- 1+ pcs$82.71
- 10+ pcs$78.03
- 100+ pcs$73.62
- 500+ pcs$69.45
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Case Connection
- ISOLATED
- Vceon Max Vge Ic
- 2.15V @ 15V, 300A
- Current Collector Cutoff Max
- 5mA
- Ntc Thermistor
- No
- Terminal Sayısı
- 5
- Kurşunsuz
- Lead Free
- Turn On Time
- 400 ns
- Montaj
- Panel, Screw
- Collectoremitter Breakdown Voltage
- 1.2kV
- RoHS Durumu
- ROHS3 Compliant
- Pin Sayısı
- 5
- Halogen Free
- Not Halogen Free
- Turn Off Timenom Toff
- 830 ns
- Configuration
- Single
- Transistor Element Material
- SILICON
- Voltage Collector Emitter Breakdown Max
- 1200V
- Fabrika Tedarik Süresi
- 14 Weeks
- Polaritychannel Type
- N-CHANNEL
- Collectoremitter Saturation Voltage
- 1.7V
- Pin Sayısı
- 5
- Input
- Standard
- Kılıf / Paket
- Module
- Terminal Formu
- UNSPECIFIED
- Çalışma Sıcaklığı
- -40°C~125°C
- Uzunluk
- 106.4mm
- ECCN Kodu
- EAR99
- Max Collector Current
- 480A
- Power Max
- 1450W
- Parça Durumu
- Active
- Terminal Pozisyonu
- UPPER
- Collector Emitter Voltage Vceo
- 1.2kV
- Yayın Yılı
- 2002
- Montaj Tipi
- Chassis Mount
- Max Power Dissipation
- 1.45kW
- Number Of Elements
- 1
- Genişlik
- 61.4mm
- Yükseklik
- 36.5mm
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance Cies Vce
- 21nF @ 25V
