Volume pricing
- 1+ pcs$927.87
- 10+ pcs$875.35
- 100+ pcs$825.80
- 500+ pcs$779.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Input
- Standard
- Reach Svhc
- Unknown
- Kılıf / Paket
- Module
- Terminal Formu
- UNSPECIFIED
- Configuration
- Half Bridge
- Turn Off Timenom Toff
- 1810 ns
- Voltage Collector Emitter Breakdown Max
- 1700V
- Transistor Element Material
- SILICON
- Fabrika Tedarik Süresi
- 10 Weeks
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 7
- Montaj
- Screw
- Turn On Time
- 930 ns
- Collectoremitter Breakdown Voltage
- 1.7kV
- RoHS Durumu
- ROHS3 Compliant
- Halogen Free
- Not Halogen Free
- Vceon Max Vge Ic
- 2.25V @ 15V, 2400A
- Case Connection
- ISOLATED
- Ntc Thermistor
- No
- Current Collector Cutoff Max
- 5mA
- Terminal Sayısı
- 7
- Kurşunsuz
- Contains Lead
- Number Of Elements
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Element Configuration
- Dual
- Currentcollector Ic Max
- 4800A
- Igbt Type
- Trench Field Stop
- Input Capacitance Cies Vce
- 195nF @ 25V
- Collector Emitter Voltage Vceo
- 1.9V
- Max Power Dissipation
- 14kW
- Montaj Tipi
- Chassis Mount
- Yayın Yılı
- 2002
- Power Max
- 13000W
- Parça Durumu
- Active
- Transistor Application
- POWER CONTROL
- Terminal Pozisyonu
- UPPER
- Çalışma Sıcaklığı
- -40°C~150°C
- Max Collector Current
- 2.4kA
