Volume pricing
- 1+ pcs$1.00
- 10+ pcs$1.00
- 25+ pcs$1.00
- 50+ pcs$1.00
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Turn Off Timenom Toff
- 1320 ns
- Configuration
- Single Switch
- Transistor Element Material
- SILICON
- Voltage Collector Emitter Breakdown Max
- 1200V
- Fabrika Tedarik Süresi
- 50 Weeks
- Polaritychannel Type
- N-CHANNEL
- Input
- Standard
- Kılıf / Paket
- Module
- Yüzey Montaj
- NO
- Terminal Formu
- UNSPECIFIED
- Case Connection
- ISOLATED
- Vceon Max Vge Ic
- 2.1V @ 15V, 2400A
- Current Collector Cutoff Max
- 5mA
- Ntc Thermistor
- No
- Terminal Sayısı
- 9
- Kurşunsuz
- Lead Free
- Turn On Time
- 880 ns
- RoHS Durumu
- ROHS3 Compliant
- Halogen Free
- Not Halogen Free
- Jesd30 Code
- R-PUFM-X9
- Yayın Yılı
- 2002
- Montaj Tipi
- Chassis Mount
- Number Of Elements
- 3
- Currentcollector Ic Max
- 3560A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Additional Feature
- UL APPROVED
- Input Capacitance Cies Vce
- 150nF @ 25V
- Igbt Type
- Trench Field Stop
- Çalışma Sıcaklığı
- -40°C~150°C
- ECCN Kodu
- EAR99
- Transistor Application
- POWER CONTROL
- Parça Durumu
- Active
- Power Max
- 13500W
- Terminal Pozisyonu
- UPPER
