Volume pricing
- 1+ pcs$1.00
- 10+ pcs$1.00
- 25+ pcs$1.00
- 50+ pcs$1.00
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Vceon Max Vge Ic
- 2.45V @ 15V, 600A
- Turn On Time
- 750 ns
- Power Max
- 8950W
- Terminal Sayısı
- 7
- Transistor Element Material
- SILICON
- Input
- Standard
- Parça Durumu
- Not For New Designs
- Qualification Status
- Not Qualified
- REACH Uyumluluk Kodu
- not_compliant
- Yayın Yılı
- 2002
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- no
- Montaj Tipi
- Chassis Mount
- RoHS Durumu
- ROHS3 Compliant
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 7
- Yüzey Montaj
- NO
- Igbt Type
- NPT
- Turn Off Timenom Toff
- 1770 ns
- Terminal Pozisyonu
- UPPER
- Ntc Thermistor
- Yes
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Jesd30 Code
- R-XUFM-X7
- Halogen Free
- Not Halogen Free
- Kurşunsuz
- Contains Lead
- Kılıf / Paket
- Module
- Terminal Formu
- UNSPECIFIED
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Voltage Collector Emitter Breakdown Max
- 1700V
- Configuration
- Three Phase Inverter
- Number Of Elements
- 2
- Fabrika Tedarik Süresi
- 12 Weeks
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Input Capacitance Cies Vce
- 145nF @ 25V
- Current Collector Cutoff Max
- 5mA
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 2300A
