Volume pricing
- 1+ pcs$788.46
- 10+ pcs$743.83
- 100+ pcs$701.73
- 500+ pcs$662.01
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Transistor Element Material
- SILICON
- Montaj
- Screw
- Input
- Standard
- Vceon Max Vge Ic
- 2.25V @ 15V, 1300A
- Turn On Time
- 1075 ns
- Power Max
- 10500W
- Terminal Sayısı
- 3
- Parça Durumu
- Active
- Yayın Yılı
- 2002
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Max Collector Current
- 1.6kA
- Montaj Tipi
- Chassis Mount
- Transistor Application
- POWER CONTROL
- Igbt Type
- Trench
- Turn Off Timenom Toff
- 2095 ns
- Ntc Thermistor
- No
- Terminal Pozisyonu
- UPPER
- Polaritychannel Type
- N-CHANNEL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Collector Emitter Voltage Vceo
- 1.7kV
- Kılıf / Paket
- Module
- Terminal Formu
- UNSPECIFIED
- Jesd30 Code
- R-XUFM-X3
- Configuration
- Single Switch
- Number Of Elements
- 3
- Voltage Collector Emitter Breakdown Max
- 1700V
- Element Configuration
- Dual
- Currentcollector Ic Max
- 1600A
- Case Connection
- ISOLATED
- Pin Sayısı
- 7
- Fabrika Tedarik Süresi
- 50 Weeks
- Current Collector Cutoff Max
- 5mA
- Input Capacitance Cies Vce
- 130nF @ 25V
- Çalışma Sıcaklığı
- -40°C~150°C
