Specifications
- Terminal Formu
- UNSPECIFIED
- Kılıf / Paket
- Module
- Jesd30 Code
- R-XUFM-X9
- Vcesatmax
- 4.25 V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Power Dissipationmax Abs
- 14500W
- Currentcollector Ic Max
- 2000A
- Case Connection
- ISOLATED
- Çalışma Sıcaklığı
- -40°C~125°C
- Input Capacitance Cies Vce
- 150nF @ 25V
- Current Collector Cutoff Max
- 12mA
- Configuration
- Full Bridge
- Number Of Elements
- 3
- Voltage Collector Emitter Breakdown Max
- 3300V
- Parça Durumu
- Last Time Buy
- Input
- Standard
- Transistor Element Material
- SILICON
- Terminal Sayısı
- 9
- Vceon Max Vge Ic
- 4.25V @ 15V, 1200A
- Turn On Time
- 480 ns
- Power Max
- 14500W
- Terminal Pozisyonu
- UPPER
- Ntc Thermistor
- No
- Turn Off Timenom Toff
- 1900 ns
- Gateemitter Voltagemax
- 20V
- Pin Sayısı
- 9
- Yüzey Montaj
- NO
- Polaritychannel Type
- N-CHANNEL
- Montaj Tipi
- Chassis Mount
- RoHS Durumu
- Non-RoHS Compliant
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- no
- Yayın Yılı
- 2002
