Volume pricing
- 1+ pcs$510.93
- 10+ pcs$482.01
- 100+ pcs$454.73
- 500+ pcs$428.99
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Transistor Element Material
- SILICON
- Input
- Standard
- Turn On Time
- 955 ns
- Vceon Max Vge Ic
- 2.3V @ 15V, 1200A
- Terminal Sayısı
- 7
- Yüzey Montaj
- NO
- Igbt Type
- Trench Field Stop
- Turn Off Timenom Toff
- 1760 ns
- Ntc Thermistor
- No
- Terminal Pozisyonu
- UPPER
- Polaritychannel Type
- N-CHANNEL
- Yayın Yılı
- 2002
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Montaj Tipi
- Chassis Mount
- Transistor Application
- POWER CONTROL
- Terminal Formu
- UNSPECIFIED
- Kılıf / Paket
- Module
- Jesd30 Code
- R-PUFM-X7
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Currentcollector Ic Max
- 1200A
- Case Connection
- ISOLATED
- Çalışma Sıcaklığı
- -40°C~150°C
- Input Capacitance Cies Vce
- 97nF @ 25V
- Current Collector Cutoff Max
- 5mA
- Number Of Elements
- 2
- Configuration
- Single Switch
- Voltage Collector Emitter Breakdown Max
- 1700V
