Volume pricing
- 1+ pcs$550.46
- 10+ pcs$519.31
- 100+ pcs$489.91
- 500+ pcs$462.18
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2002
- RoHS Durumu
- ROHS3 Compliant
- Montaj Tipi
- Chassis Mount
- ECCN Kodu
- EAR99
- Transistor Application
- POWER CONTROL
- Igbt Type
- Trench Field Stop
- Yüzey Montaj
- NO
- Terminal Pozisyonu
- UPPER
- Ntc Thermistor
- No
- Turn Off Timenom Toff
- 1130 ns
- Polaritychannel Type
- N-CHANNEL
- Input
- Standard
- Transistor Element Material
- SILICON
- Vceon Max Vge Ic
- 2.1V @ 15V, 1200A
- Turn On Time
- 660 ns
- Terminal Sayısı
- 7
- Parça Durumu
- Active
- Configuration
- Single Switch
- Number Of Elements
- 2
- Voltage Collector Emitter Breakdown Max
- 1200V
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 1825A
- Fabrika Tedarik Süresi
- 52 Weeks
- Çalışma Sıcaklığı
- -40°C~150°C
- Input Capacitance Cies Vce
- 74nF @ 25V
- Current Collector Cutoff Max
- 5mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Formu
- UNSPECIFIED
- Kılıf / Paket
- Module
- Jesd30 Code
- R-PUFM-X7
