Specifications
- Configuration
- Single Switch
- Number Of Elements
- 2
- Element Configuration
- Dual
- Voltage Collector Emitter Breakdown Max
- 3300V
- Pin Sayısı
- 7
- Currentcollector Ic Max
- 1000A
- Case Connection
- ISOLATED
- Current Collector Cutoff Max
- 5mA
- Input Capacitance Cies Vce
- 190nF @ 25V
- Çalışma Sıcaklığı
- -40°C~150°C
- Collector Emitter Voltage Vceo
- 3.3kV
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kılıf / Paket
- Module
- Terminal Formu
- UNSPECIFIED
- Kurşunsuz
- Contains Lead
- Halogen Free
- Not Halogen Free
- RoHS Durumu
- ROHS3 Compliant
- Montaj Tipi
- Chassis Mount
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2002
- Ntc Thermistor
- No
- Terminal Pozisyonu
- UPPER
- Turn Off Timenom Toff
- 4700 ns
- Igbt Type
- Trench Field Stop
- Polaritychannel Type
- N-CHANNEL
- Input
- Standard
- Transistor Element Material
- SILICON
- Montaj
- Screw
- Terminal Sayısı
- 7
- Vceon Max Vge Ic
- 2.85V @ 15V, 1000A
- Turn On Time
- 1050 ns
- Power Max
- 1600W
- Parça Durumu
- Active
