Volume pricing
- 1+ pcs$49.22
- 10+ pcs$46.43
- 100+ pcs$43.80
- 500+ pcs$41.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- ROHS3 Compliant
- Pin Sayısı
- 33
- Halogen Free
- Not Halogen Free
- Turn On Time
- 185 ns
- Montaj
- Screw
- Collectoremitter Breakdown Voltage
- 1.2kV
- Terminal Sayısı
- 15
- Kurşunsuz
- Contains Lead
- Case Connection
- ISOLATED
- Vceon Max Vge Ic
- 2.15V @ 15V, 75A
- Current Collector Cutoff Max
- 1mA
- Ntc Thermistor
- Yes
- Terminal Formu
- UNSPECIFIED
- Reach Svhc
- No SVHC
- Input
- Standard
- Kılıf / Paket
- Module
- Fabrika Tedarik Süresi
- 16 Weeks
- Qualification Status
- Not Qualified
- Pin Sayısı
- 18
- Collectoremitter Saturation Voltage
- 2.15V
- Polaritychannel Type
- N-CHANNEL
- Turn Off Timenom Toff
- 490 ns
- Configuration
- Full Bridge
- Transistor Element Material
- SILICON
- Voltage Collector Emitter Breakdown Max
- 1200V
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Parça Durumu
- Active
- Transistor Application
- POWER CONTROL
- Terminal Pozisyonu
- UPPER
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Max Collector Current
- 107A
- ECCN Kodu
- EAR99
- Çalışma Sıcaklığı
- -40°C~150°C
- Kurşunsuz Kodu
- no
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance Cies Vce
- 4.3nF @ 25V
- Power Dissipation
- 375W
- Igbt Type
- Trench Field Stop
- Number Of Elements
- 6
- Yayın Yılı
- 2002
