Volume pricing
- 1+ pcs$40.05
- 10+ pcs$37.78
- 100+ pcs$35.64
- 500+ pcs$33.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- ROHS3 Compliant
- Turn On Time
- 185 ns
- Terminal Sayısı
- 18
- Vceon Max Vge Ic
- 2.15V @ 15V, 50A
- Ntc Thermistor
- Yes
- Current Collector Cutoff Max
- 1mA
- Yüzey Montaj
- NO
- Terminal Formu
- UNSPECIFIED
- Input
- Standard
- Kılıf / Paket
- Module
- Fabrika Tedarik Süresi
- 16 Weeks
- Polaritychannel Type
- N-CHANNEL
- Configuration
- Three Phase Inverter
- Turn Off Timenom Toff
- 490 ns
- Voltage Collector Emitter Breakdown Max
- 1200V
- Transistor Element Material
- SILICON
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Power Max
- 335W
- Parça Durumu
- Active
- Transistor Application
- POWER CONTROL
- Terminal Pozisyonu
- UPPER
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- ECCN Kodu
- EAR99
- Çalışma Sıcaklığı
- -40°C~150°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Currentcollector Ic Max
- 83A
- Igbt Type
- Trench Field Stop
- Input Capacitance Cies Vce
- 2.8nF @ 25V
- Number Of Elements
- 6
- Montaj Tipi
- Chassis Mount
- Yayın Yılı
- 2002
- Jesd30 Code
- R-XUFM-X18
