Volume pricing
- 1+ pcs$27.14
- 10+ pcs$25.61
- 100+ pcs$24.16
- 500+ pcs$22.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Input
- Standard
- RoHS Durumu
- ROHS3 Compliant
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Parça Durumu
- Active
- Configuration
- Three Phase Inverter
- Seri
- EasyPACK™ 1B
- Pin Sayısı
- 18
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 250 ns
- Çalışma Sıcaklığı
- -40°C~150°C
- Currentcollector Ic Max
- 70A
- Case Connection
- ISOLATED
- Fabrika Tedarik Süresi
- 16 Weeks
- Number Of Elements
- 6
- Power Dissipation
- 205W
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Halogen Free
- Not Halogen Free
- Polaritychannel Type
- N-CHANNEL
- Igbt Type
- Trench Field Stop
- Ntc Thermistor
- Yes
- Montaj
- Screw
- Kurşunsuz
- Contains Lead
- Montaj Tipi
- Chassis Mount
- Max Collector Current
- 70A
- Collector Emitter Voltage Vceo
- 600V
- Input Capacitance Cies Vce
- 3.1nF @ 25V
- Collectoremitter Saturation Voltage
- 1.45V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Transistor Application
- POWER CONTROL
- Terminal Sayısı
- 18
- Terminal Pozisyonu
- UPPER
- Vceon Max Vge Ic
- 1.9V @ 15V, 50A
- Turn Off Timenom Toff
- 370 ns
- Additional Feature
- UL RECOGNIZED
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2002
- Current Collector Cutoff Max
- 1mA
