Volume pricing
- 1+ pcs$589.34
- 10+ pcs$555.98
- 100+ pcs$524.51
- 500+ pcs$494.82
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Polaritychannel Type
- N-CHANNEL
- Igbt Type
- Trench Field Stop
- Ntc Thermistor
- Yes
- Montaj Tipi
- Chassis Mount
- Voltage Collector Emitter Breakdown Max
- 1700V
- Input Capacitance Cies Vce
- 40nF @ 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Transistor Application
- POWER CONTROL
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 29
- Vceon Max Vge Ic
- 2.3V @ 15V, 500A
- Turn Off Timenom Toff
- 1080 ns
- Additional Feature
- UL RECOGNIZED
- Transistor Element Material
- SILICON
- Yayın Yılı
- 2002
- Current Collector Cutoff Max
- 3mA
- Yüzey Montaj
- NO
- Power Max
- 20mW
- RoHS Durumu
- ROHS3 Compliant
- Input
- Standard
- Jesd30 Code
- R-XUFM-X29
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Parça Durumu
- Active
- Configuration
- Full Bridge
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 330 ns
- Çalışma Sıcaklığı
- -40°C~150°C
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 1000A
- Fabrika Tedarik Süresi
- 26 Weeks
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Elements
- 6
