Volume pricing
- 1+ pcs$321.99
- 10+ pcs$303.77
- 100+ pcs$286.57
- 500+ pcs$270.35
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- ROHS3 Compliant
- Input
- Standard
- Jesd30 Code
- R-XUFM-X29
- Power Max
- 20mW
- Configuration
- Full Bridge
- Parça Durumu
- Active
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Terminal Formu
- UNSPECIFIED
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Elements
- 6
- Fabrika Tedarik Süresi
- 26 Weeks
- Currentcollector Ic Max
- 900A
- Case Connection
- ISOLATED
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn On Time
- 290 ns
- Polaritychannel Type
- N-CHANNEL
- Ntc Thermistor
- Yes
- Igbt Type
- Trench Field Stop
- Transistor Application
- POWER CONTROL
- Input Capacitance Cies Vce
- 1.55nF @ 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Collector Emitter Breakdown Max
- 1200V
- Montaj Tipi
- Chassis Mount
- Yüzey Montaj
- NO
- Current Collector Cutoff Max
- 3mA
- Yayın Yılı
- 2002
- ECCN Kodu
- EAR99
- Transistor Element Material
- SILICON
- Additional Feature
- UL RECOGNIZED
- Vceon Max Vge Ic
- 2.1V @ 15V, 450A
- Turn Off Timenom Toff
- 680 ns
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 29
