Volume pricing
- 1+ pcs$473.59
- 10+ pcs$446.78
- 100+ pcs$421.49
- 500+ pcs$397.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Not For New Designs
- Pin Sayısı
- 29
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Configuration
- Full Bridge
- RoHS Durumu
- ROHS3 Compliant
- Input
- Standard
- Power Max
- 2250W
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn On Time
- 290 ns
- Number Of Elements
- 6
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Case Connection
- ISOLATED
- Contact Plating
- Tin
- Pin Sayısı
- 29
- Seri
- EconoPACK™+
- Terminal Formu
- UNSPECIFIED
- Igbt Type
- Trench Field Stop
- Montaj
- Screw
- Qualification Status
- Not Qualified
- Kurşunsuz
- Contains Lead
- Ntc Thermistor
- Yes
- Polaritychannel Type
- N-CHANNEL
- Halogen Free
- Not Halogen Free
- Turn Off Timenom Toff
- 740 ns
- Vceon Max Vge Ic
- 2.1V @ 15V, 450A
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 29
- Current Collector Cutoff Max
- 3mA
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2002
- Collector Emitter Voltage Vceo
- 1.2kV
- Kurşunsuz Kodu
- no
- Max Collector Current
- 675A
- Montaj Tipi
- Chassis Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance Cies Vce
- 28nF @ 25V
- Voltage Collector Emitter Breakdown Max
- 1200V
