Volume pricing
- 1+ pcs$510.69
- 10+ pcs$481.79
- 100+ pcs$454.51
- 500+ pcs$428.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pin Sayısı
- 29
- RoHS Durumu
- ROHS3 Compliant
- Vceon Max Vge Ic
- 2.45V @ 15V, 300A
- Max Collector Current
- 375A
- Turn Off Timenom Toff
- 1300 ns
- ECCN Kodu
- EAR99
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Power Dissipation
- 1.65kW
- Power Max
- 1650W
- Halogen Free
- Not Halogen Free
- Igbt Type
- Trench Field Stop
- Collectoremitter Breakdown Voltage
- 1.7kV
- Qualification Status
- Not Qualified
- Seri
- EconoPACK™+
- Montaj
- Screw
- Transistor Element Material
- SILICON
- Kılıf / Paket
- Module
- Kurşunsuz
- Contains Lead
- Current Collector Cutoff Max
- 3mA
- Contact Plating
- Tin
- Number Of Elements
- 6
- Kurşunsuz Kodu
- no
- Parça Durumu
- Not For New Designs
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Collectoremitter Saturation Voltage
- 2.45V
- Terminal Pozisyonu
- UPPER
- Yayın Yılı
- 2002
- Input Capacitance Cies Vce
- 27nF @ 25V
- Turn On Time
- 384 ns
- Case Connection
- ISOLATED
- Terminal Formu
- UNSPECIFIED
- Terminal Sayısı
- 29
- Voltage Collector Emitter Breakdown Max
- 1700V
- Input
- Standard
- Çalışma Sıcaklığı
- -40°C~125°C
- Pin Sayısı
- 29
- Polaritychannel Type
- N-CHANNEL
- Collector Emitter Voltage Vceo
- 1.7kV
- Ntc Thermistor
- Yes
