Volume pricing
- 1+ pcs$278.40
- 10+ pcs$262.64
- 100+ pcs$247.77
- 500+ pcs$233.75
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Additional Feature
- UL RECOGNIZED
- Currentcollector Ic Max
- 600A
- RoHS Durumu
- Non-RoHS Compliant
- Vceon Max Vge Ic
- 2.1V @ 15V, 300A
- Max Collector Current
- 460A
- ECCN Kodu
- EAR99
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Turn Off Timenom Toff
- 650 ns
- Montaj
- Screw
- Power Max
- 20mW
- Igbt Type
- Trench Field Stop
- Kılıf / Paket
- Module
- Current Collector Cutoff Max
- 3mA
- Fabrika Tedarik Süresi
- 52 Weeks
- Transistor Element Material
- SILICON
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Jesd30 Code
- R-XUFM-X29
- Number Of Elements
- 6
- Parça Durumu
- Active
- Turn On Time
- 280 ns
- Terminal Formu
- UNSPECIFIED
- Case Connection
- ISOLATED
- Terminal Sayısı
- 29
- Yayın Yılı
- 2002
- Terminal Pozisyonu
- UPPER
- Transistor Application
- POWER CONTROL
- Input Capacitance Cies Vce
- 18.5nF @ 25V
- Collector Emitter Voltage Vceo
- 1.2kV
- Ntc Thermistor
- Yes
- Voltage Collector Emitter Breakdown Max
- 1200V
- Input
- Standard
- Çalışma Sıcaklığı
- -40°C~150°C
- Polaritychannel Type
- N-CHANNEL
- Montaj Tipi
- Chassis Mount
- Configuration
- Full Bridge
