Volume pricing
- 1+ pcs$381.04
- 10+ pcs$359.47
- 100+ pcs$339.13
- 500+ pcs$319.93
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yüzey Montaj
- NO
- RoHS Durumu
- ROHS3 Compliant
- Currentcollector Ic Max
- 500A
- Vceon Max Vge Ic
- 2.15V @ 15V, 300A
- Turn Off Timenom Toff
- 810 ns
- ECCN Kodu
- EAR99
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Power Max
- 1450W
- Igbt Type
- Trench Field Stop
- Qualification Status
- Not Qualified
- Transistor Element Material
- SILICON
- Kılıf / Paket
- Module
- Current Collector Cutoff Max
- 5mA
- Fabrika Tedarik Süresi
- 14 Weeks
- Jesd30 Code
- R-XUFM-X29
- Number Of Elements
- 6
- Kurşunsuz Kodu
- no
- Parça Durumu
- Not For New Designs
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Yayın Yılı
- 2002
- Terminal Pozisyonu
- UPPER
- Input Capacitance Cies Vce
- 21nF @ 25V
- Turn On Time
- 400 ns
- Case Connection
- ISOLATED
- Terminal Formu
- UNSPECIFIED
- Terminal Sayısı
- 29
- Voltage Collector Emitter Breakdown Max
- 1200V
- Input
- Standard
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Pin Sayısı
- 29
- Polaritychannel Type
- N-CHANNEL
- Ntc Thermistor
- Yes
- Montaj Tipi
- Chassis Mount
- Configuration
- Three Phase Inverter
