Specifications
- RoHS Durumu
- ROHS3 Compliant
- Currentcollector Ic Max
- 450A
- Additional Feature
- UL RECOGNIZED
- Turn Off Timenom Toff
- 570 ns
- ECCN Kodu
- EAR99
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Max Collector Current
- 350A
- Vceon Max Vge Ic
- 2.15V @ 15V, 225A
- Montaj
- Screw
- Igbt Type
- Trench Field Stop
- Power Max
- 20mW
- Fabrika Tedarik Süresi
- 26 Weeks
- Current Collector Cutoff Max
- 3mA
- Kılıf / Paket
- Module
- Transistor Element Material
- SILICON
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Parça Durumu
- Active
- Number Of Elements
- 6
- Jesd30 Code
- R-XUFM-X29
- Terminal Sayısı
- 29
- Case Connection
- ISOLATED
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 230 ns
- Input Capacitance Cies Vce
- 13nF @ 25V
- Transistor Application
- POWER CONTROL
- Yayın Yılı
- 2002
- Terminal Pozisyonu
- UPPER
- Collector Emitter Voltage Vceo
- 1.2kV
- Ntc Thermistor
- Yes
- Polaritychannel Type
- N-CHANNEL
- Input
- Standard
- Çalışma Sıcaklığı
- -40°C~150°C
- Voltage Collector Emitter Breakdown Max
- 1200V
- Configuration
- Full Bridge
- Montaj Tipi
- Chassis Mount
