Volume pricing
- 1+ pcs$304.07
- 10+ pcs$286.86
- 100+ pcs$270.62
- 500+ pcs$255.30
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yüzey Montaj
- NO
- RoHS Durumu
- ROHS3 Compliant
- Currentcollector Ic Max
- 320A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- ECCN Kodu
- EAR99
- Turn Off Timenom Toff
- 600 ns
- Vceon Max Vge Ic
- 2.15V @ 15V, 225A
- Igbt Type
- Trench Field Stop
- Power Max
- 1100W
- Qualification Status
- Not Qualified
- Seri
- EconoPACK™+
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 3mA
- Kılıf / Paket
- Module
- Parça Durumu
- Not For New Designs
- Kurşunsuz Kodu
- no
- Number Of Elements
- 6
- Jesd30 Code
- R-XUFM-X29
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Input Capacitance Cies Vce
- 13nF @ 25V
- Yayın Yılı
- 2002
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 29
- Case Connection
- ISOLATED
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 220 ns
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 29
- Çalışma Sıcaklığı
- -40°C~150°C
- Input
- Standard
- Voltage Collector Emitter Breakdown Max
- 1200V
- Ntc Thermistor
- Yes
- Configuration
- Full Bridge
- Montaj Tipi
- Chassis Mount
