Volume pricing
- 1+ pcs$326.86
- 10+ pcs$308.36
- 100+ pcs$290.91
- 500+ pcs$274.44
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 162mm
- RoHS Durumu
- ROHS3 Compliant
- Pin Sayısı
- 28
- Yükseklik
- 17mm
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- ECCN Kodu
- EAR99
- Turn Off Timenom Toff
- 810 ns
- Max Collector Current
- 325A
- Vceon Max Vge Ic
- 2.15V @15V, 225A
- Montaj
- Screw
- Qualification Status
- Not Qualified
- Seri
- EconoPACK™+
- Collectoremitter Breakdown Voltage
- 1.2kV
- Igbt Type
- Trench Field Stop
- Halogen Free
- Not Halogen Free
- Power Max
- 1150W
- Fabrika Tedarik Süresi
- 20 Weeks
- Kurşunsuz
- Contains Lead
- Current Collector Cutoff Max
- 5mA
- Kılıf / Paket
- Module
- Transistor Element Material
- SILICON
- Collectoremitter Saturation Voltage
- 1.7V
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Not For New Designs
- Kurşunsuz Kodu
- no
- Number Of Elements
- 6
- Jesd30 Code
- R-XUFM-X29
- Terminal Sayısı
- 29
- Terminal Formu
- UNSPECIFIED
- Case Connection
- ISOLATED
- Turn On Time
- 400 ns
- Input Capacitance Cies Vce
- 16nF @ 25V
- Max Power Dissipation
- 1.15kW
- Yayın Yılı
- 2002
- Terminal Pozisyonu
- UPPER
- Ntc Thermistor
- Yes
- Collector Emitter Voltage Vceo
- 1.2kV
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 29
