Volume pricing
- 1+ pcs$20.00
- 10+ pcs$18.86
- 100+ pcs$17.80
- 500+ pcs$16.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Igbt Type
- Trench Field Stop
- Qualification Status
- Not Qualified
- Ntc Thermistor
- Yes
- Polaritychannel Type
- N-CHANNEL
- Vceon Max Vge Ic
- 2V @ 15V, 20A
- Turn Off Timenom Toff
- 320 ns
- Terminal Sayısı
- 15
- Terminal Pozisyonu
- UPPER
- Current Collector Cutoff Max
- 1mA
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2002
- Yüzey Montaj
- NO
- Kurşunsuz Kodu
- no
- Montaj Tipi
- Chassis Mount
- Voltage Collector Emitter Breakdown Max
- 600V
- Transistor Application
- POWER CONTROL
- Input Capacitance Cies Vce
- 1.1nF @ 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pin Sayısı
- 22
- Parça Durumu
- Active
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Kılıf / Paket
- Module
- Configuration
- Three Phase Inverter
- Power Max
- 135W
- RoHS Durumu
- ROHS3 Compliant
- Jesd30 Code
- R-XUFM-X15
- Input
- Standard
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn On Time
- 57 ns
- Fabrika Tedarik Süresi
- 16 Weeks
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 35A
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Elements
- 6
- Seri
- EasyPACK™ 1B
- Terminal Formu
- UNSPECIFIED
