Volume pricing
- 1+ pcs$4.38
- 10+ pcs$4.13
- 100+ pcs$3.90
- 500+ pcs$3.68
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Transistor Element Material
- SILICON
- Yayın Yılı
- 2002
- ECCN Kodu
- EAR99
- Current Collector Cutoff Max
- 1mA
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 13
- Turn Off Timenom Toff
- 250 ns
- Vceon Max Vge Ic
- 2V @ 15V, 20A
- Input Capacitance Cies Vce
- 1.1nF @ 25V
- Collectoremitter Saturation Voltage
- 1.55V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- no
- Max Collector Current
- 25A
- Montaj Tipi
- Chassis Mount
- Collector Emitter Voltage Vceo
- 600V
- Ntc Thermistor
- No
- Montaj
- Screw
- Kurşunsuz
- Contains Lead
- Halogen Free
- Not Halogen Free
- Polaritychannel Type
- N-CHANNEL
- Currentcollector Ic Max
- 25A
- Power Dissipation
- 71.5W
- Number Of Elements
- 6
- Turn On Time
- 320 ns
- Çalışma Sıcaklığı
- -40°C~150°C
- Terminal Formu
- WIRE
- Pin Sayısı
- 13
- Contact Plating
- Tin
- Configuration
- Three Phase Inverter
- Kılıf / Paket
- Module
- Parça Durumu
- Not For New Designs
- Pin Sayısı
- 13
- RoHS Durumu
- RoHS Compliant
- Input
- Standard
