Specifications
- Yüzey Montaj
- NO
- Current Collector Cutoff Max
- 1mA
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2013
- Additional Feature
- UL RECOGNIZED
- Vceon Max Vge Ic
- 2.15V @ 15V, 200A
- Turn Off Timenom Toff
- 600 ns
- Terminal Sayısı
- 35
- Terminal Pozisyonu
- UPPER
- Transistor Application
- POWER CONTROL
- Input Capacitance Cies Vce
- 14nF @ 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Collector Emitter Breakdown Max
- 1200V
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- no
- Qualification Status
- Not Qualified
- Kurşunsuz
- Contains Lead
- Ntc Thermistor
- Yes
- Igbt Type
- NPT
- Polaritychannel Type
- N-CHANNEL
- Halogen Free
- Not Halogen Free
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Elements
- 6
- Fabrika Tedarik Süresi
- 16 Weeks
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 280A
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Turn On Time
- 190 ns
- Terminal Formu
- UNSPECIFIED
- Configuration
- Three Phase Inverter
- Pin Sayısı
- 35
- Parça Durumu
- Active
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Kılıf / Paket
- Module
- RoHS Durumu
- ROHS3 Compliant
- Jesd30 Code
- R-XUFM-X35
- Input
- Standard
- Power Max
- 1000W
