Specifications
- Çalışma Sıcaklığı
- -40°C~125°C
- Turn On Time
- 72 ns
- Max Power Dissipation
- 86W
- Number Of Elements
- 6
- Fabrika Tedarik Süresi
- 16 Weeks
- Case Connection
- ISOLATED
- Pin Sayısı
- 11
- Terminal Formu
- UNSPECIFIED
- Pin Sayısı
- 11
- Parça Durumu
- Not For New Designs
- Uzunluk
- 32.4mm
- Kılıf / Paket
- Module
- Configuration
- Three Phase Inverter
- Genişlik
- 25.4mm
- Input
- Standard
- RoHS Durumu
- RoHS Compliant
- Power Max
- 86W
- Vceon Max Vge Ic
- 2.15V @ 15V, 15A
- Turn Off Timenom Toff
- 590 ns
- Terminal Sayısı
- 11
- Terminal Pozisyonu
- UPPER
- Current Collector Cutoff Max
- 1mA
- Transistor Element Material
- SILICON
- Yayın Yılı
- 2002
- ECCN Kodu
- EAR99
- Collector Emitter Voltage Vceo
- 1.2kV
- Montaj Tipi
- Chassis Mount
- Max Collector Current
- 24A
- Kurşunsuz Kodu
- no
- Input Capacitance Cies Vce
- 1.1nF @ 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Collector Emitter Breakdown Max
- 1200V
- Yükseklik
- 12mm
- Montaj
- PCB, Screw
- Kurşunsuz
- Contains Lead
- Ntc Thermistor
- No
- Polaritychannel Type
- N-CHANNEL
- Halogen Free
- Not Halogen Free
