Volume pricing
- 1+ pcs$120.11
- 10+ pcs$113.31
- 100+ pcs$106.89
- 500+ pcs$100.84
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Currentcollector Ic Max
- 150A
- Case Connection
- ISOLATED
- Fabrika Tedarik Süresi
- 26 Weeks
- Number Of Elements
- 6
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Turn On Time
- 280 ns
- Çalışma Sıcaklığı
- -40°C~150°C
- Terminal Formu
- UNSPECIFIED
- Configuration
- Three Phase Inverter
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Parça Durumu
- Active
- Pin Sayısı
- 20
- Power Max
- 835W
- RoHS Durumu
- RoHS Compliant
- Input
- Standard
- Jesd30 Code
- R-XUFM-X13
- Yayın Yılı
- 2002
- ECCN Kodu
- EAR99
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 1mA
- Yüzey Montaj
- NO
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 13
- Vceon Max Vge Ic
- 2.3V @ 15V, 150A
- Turn Off Timenom Toff
- 1240 ns
- Voltage Collector Emitter Breakdown Max
- 1700V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance Cies Vce
- 13.5nF @ 25V
- Transistor Application
- POWER CONTROL
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- no
- Ntc Thermistor
- Yes
- Qualification Status
- Not Qualified
- Kurşunsuz
- Contains Lead
- Igbt Type
- Trench Field Stop
- Halogen Free
- Not Halogen Free
- Polaritychannel Type
- N-CHANNEL
